Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machines. They make equipment such as boom lifts, aerial lifts and manlifts. These machines are designed to facilitate access to areas that are hard to reach, roofs and buildings, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and includes handholds or platforms or steps which are connected to the unit to be able to transport workers from every floor.
TB85
The Terex TB85 offers a maximum working height of 91 feet. Moreover, the platform's maximum height reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions that measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model offers a reach of seventy feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height reaches 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
